Natalie 2 house plan

Usable area: 180.49 m² / The cost of the realization: 153 200 EUR

House plan Natalie 2 - front visualization

Show mirror image

Price: 1040 EUR

Description Plans Elevations Situations Animation Variants (0) Realizations (25) Detailed drawings List of materials Comments (3)

Natalie 2 is a variant version of the Natalia house plan. In this version, the house is designed so that it also fit to plot with entering of adverse terms of the world. Living room at this house has been planned in such a way that it can be illuminated by the sun on both the front and back of the house. On the ground floor two additional rooms with private bathrooms and a garage for two cars has been designed. In the attic there are three nice bedrooms with a large bathroom and attic - laundry / dryer. Attic can be finished in the second stage. It can also be excluded from the usable area of the house, leaving the attic. There is also a mirror version of the Natalie 2 house plan.

Specifications:

Cubature: 797 m³ / 28142,07 ft³
Built-up area: 181,11 m² / 1948,74 ft²
Total area: 282,44 m² / 3039,05 ft²
Net area: 195,24 m²+ garage+ attic / 2100,78 ft² + garage+ attic
Usable area: 180,49 m² / 1942,07 ft²
Roof area: 326,26 m² / 3510,56 ft²
Roof slope: 40 and 35 degrees
Height of the building: 8,21 m ( 8,61 m with foundation) / 26,93 ft ( 28,24 ft with foundation)
Wide of the building: 13,45 m / 44,12 ft
Length of the building: 16,44 m / 53,92 ft
Minimum plot width: 21,45 m / 70,36 ft
Minimum plot length: 24,44 m / 80,16 ft
Height of rooms: 2,80 m / 9,18 ft

Materials:

Foundations - concrete bench and foundation walls with concrete blocks
External walls - bilayer - porotherm blocks
Ceiling - Teriva
Roof - tile
Elevation - thin-layer plaster

The costs of implementing:

The raw state open	55 200,00 EUR
The raw state closed	79 000,00 EUR
The cost of finishing works	74 200,00 EUR
Execution of turnkey home	153 200,00 EUR

Net notified costs, do not include VAT

Order

Additions to the project:

Energy-saving package free

Ventilation and fireplace package 90,00 EUR

Central vacuum package 70,00 EUR

The electronic version of the project 120,00 EUR

Solar installation package 70,00 EUR

Underfloor heating package 80,00 EUR

Heat pump package 70,00 EUR

Water jacket package 70,00 EUR

Boiler for solid fuel package 80,00 EUR

Air conditioning package 80,00 EUR

Fencing projects 140,00 EUR

Septic tanks sealed package free

Natalia 2 - zestawienie materiałowe

To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.

House plan Natalie 2 - detailed file

House plan Natalie 2 - detailed file - mirror
