Usable area: 193.82 m2 / The cost of the realization: 148 800 EUR
Show mirror image
Price: 1070 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Realizations (4) Detailed drawings
List of materials
Comments (3)
Eco house plan is a house for a family of 4 - 5 people. This is a perfect house for people who expect originality and maintaining good taste. Eco house plan uses the language of modern details such as large windows, open space, rectangular bay windows or a terrace on the garage roof. The house is designed for maximum opening to the garden. An additional attraction is the terrace above the garage on the attic.
Specifications:
- Cubature: 887 m3/ 31319,97 ft3
- Built-up area: 191,25 m2/ 2057,85 ft2
- Total area: 283,71 m2/ 3052,72 ft2
- Net area: 193,82 m2 + garage/ 2085,50 ft2 + garage
- Usable area: 193,82 m2/ 2085,50 ft2
- Roof area: 216,12 m2/ 2325,45 ft2
- Roof slope: 40 degrees
- Height of the building: 8,09 m (8,60 m with foundation)/ 26,53 ft (28,21 ft with foundation)
- Wide of the building: 23,06 m / 75,64 ft
- Length of the building: 10,91 m / 35,79 ft
- Minimum plot width: 31,06 m / 101,88 ft
- Minimum plot length: 18,91 m / 62,03 ft
- Height of rooms: 2,70 m / 8,86 ft
Materials:
• Foundations – reinforced concrete
• External walls - bilayer – U220 or porotherm 25 + mineral wool 15
• Ceiling - reinforced concrete Teriva
• Elevation - thin-layer plaster
• Roof - ceramic tile
The costs of implementing:
| The raw state open | 61 000,00 EUR |
| The raw state closed | 84 800,00 EUR |
| The cost of finishing works | 64 000,00 EUR |
| Execution of turnkey home | 148 800,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Eco - detailed file
House plan Eco - detailed file - mirror
