Usable area: 172.9 m2 / The cost of the realization: 140 600 EUR
Show mirror image
Price: 1040 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Detailed drawings
List of materials
Comments (3)
Gagatek house plan is a detached house for a family of four-six people. One-storey house with a usable attic, and a garage covered by a gable roofs. Ground floor plan was built on a square plan with a clear division of structural walls into nine smaller parts. This principle gives a very clear, simple and clean structural system of the building, which will facilitate implementation. In the house plan also external architecture is subordinated to the principle of symmetry - the only exception is a garage adjoined on the side. Traditional style of house, with entrance arcades and columns, with a centrally mounted dormers and a side bay window of the dining room is combined here with the applied of modern materials. The whole gives an universal, timeless and unpretentious expression. Inside the house, on the ground floor living space with a large living room, dining room, lounge and partially open kitchen is designed. The ground floor also provides space for a separate room - office or bedroom, and a boiler room and garage. There are four bedrooms in the attic, including a parents' bedroom with dressing room and a comfortable bathroom. Gagatek house plan is also available in mirror version.
Specifications:
- Cubature: 768 m3/27118,08 ft3
- Built-up area: 153,75 m2/ 1654,35 ft2
- Total area: 257,3 m2/ 2768,55 ft2
- Net area : 186,51 m2 + garage/ 2006,85 ft2
- Usable area: 172,9 m2/ 1860,40 ft2
- Roof area: 274,57 m2/ 2954,37 ft2
- Roof slope: 40 degrees
- Height of the building: 8,92 m (9,27 m with foundation)/ 29,26 ft (30,41 ft with foundation)
- Wide of the building: 15,67 m/ 51,40 ft
- Length of the building: 12,51 m/ 41,04 ft
- Minimum plot width: 22,67 m/ 74,36 ft
- Minimum plot length: 21,21 m/ 69,57 ft
- Height of rooms: 2,8 m/ 9,18 ft
Materials:
- Foundations: concrete benches and foundation walls of concrete blocks
- External walls brick walls - porotherm 25 hollow + polystyrene + thin-layer plaster
- Ceiling: Teriva
- Elevations: thin-layer plaster on polystyrene
- Roofing: tile
The costs of implementing:
| The raw state open | 56 300,00 EUR |
| The raw state closed | 80 100,00 EUR |
| The cost of finishing works | 60 500,00 EUR |
| Execution of turnkey home | 140 600,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Gagatek - detailed file
House plan Gagatek - detailed file - mirror
