Ruby 3 house plan

Usable area: 187.05 m2   /   The cost of the realization: 144 300 EUR
House plan Ruby 3 - front visualization
Show mirror image

House Ruby 3 is a variant version of the popular house Ruby. In relation to the basic version house Ruby 3 is reduced, has single garage and built-emptiness of the living room in the attic. House is designed for a family of five - to six people. Storey block with usable attic, consists of residential part and built another on the side garage. The entire house of the building is covered with a hipped roof with large dormers on each elevation. Quiet suburban architecture of house interesting details, such as bay windows, porches with columns and arched windows, balconies, connects with functionally designed interior of the building. A special attraction is a large front dormer with entrance porch and columns. From the garden and a large arcade, where under the roofed you can shelter from the rain or hot sun. Interior of the ground floor house Ruby 3 is primarily open daily space, with living room, dining room and hall. On the ground floor was designed kitchen and extra room which could serve as office or bedroom or for example, a guest bedroom. They fit also utility rooms - a boiler room and a garage with facilities garden. In the attic there are was planned five bedrooms with dressing rooms and built-in wardrobes, a large bathroom and a laundry-drying. House is ideal for a large family with many children. There is also available mirror version of this house plan.

  • Cubature: 798 m3 / 28177,38 ft2
  • Built-up area: 157,43 m2 / 1693,95 ft2
  • Total area: 276,78 m2 / 2978,15 ft2
  • Net area: 211,8 m2 + garage / 2278,97 ft2 + garage
  • Usable area: 187,05 m2 / 2012,66 ft2
  • Roof area: 297,13 m2 / 3197,12 ft2
  • Roof slope: 34m, 39 and 45 degrees
  • Height of the building: 8,55 (9,00 m with foundation) / 28,04 ft (29,52 ft with foundation)
  • Wide of the building: 16,39 m /  53,76 ft
  • Length of the building 11,39 m / 37,36 ft
  • Minimum plot width: 25,32 m / 83,05 ft
  • Minimum plot length: 19,45 m / 63,80 ft
  • Height of rooms: 2,8 i 2,65 m / 9,18 and 8,69 ft
  • Foundations - concrete bench and foundation walls with concrete blocks
  • External walls –  brick walls –porotherm blocks + polystyrene + thin-layer plaster
  • Ceiling -  Teriva
  • Elevation - thin-layer plaster on polystyrene
  • Roof - tile



The costs of implementing:
The raw state open 49 500,00 EUR
The raw state closed 76 600,00 EUR
The cost of finishing works 67 800,00 EUR
Execution of turnkey home 144 300,00 EUR

Net notified costs, do not include VAT

To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.

House plan Ruby 3 - detailed file

House plan Ruby 3 - detailed file - mirror
