Usable area: 287.56 m2 / The cost of the realization: 208 700 EUR
Show mirror image
Price: 1250 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Realizations (9) Detailed drawings
List of materials
Comments (3)
Ash tree house plan is a large, comfortable detached house for a nice plot. The building has been designed for the family of 4 to 7 people, with the possibility of fencing housing for seniors. The house plan of villa is scheduled on L-shaped so as to provide maximum protection and intimacy for a large, partially covered terrace. It's the perfect place to rest. The living area consists of living room, dining room, lounge and a large kitchen. In the lobby an elegant staircase wrapped around the central massive fireplace wall was designed. On the attic there are four bedrooms with bathrooms and dressing rooms there is also enlarge hall that can serve as a living room or tv room. Outside in the arcade garden the outdoor fireplace was also designed. There is also available a mirror version of the Ash tree house plan.
Specifications:
- Cubature: 1230 m3/43431,3 ft3
- Built-up area: 245,56 m2// 2642,23 ft2
- Total area: 391,47 m2/ 4212,22 ft2
- Net area: 310,58 m2 + garage/ 3341,84 ft2 + garage
- Usable area: 287,56 m2/ 3094,15 ft2
- Roof area: 460 m2/ 4949,60 ft2
- Roof slope: 43 degrees
- Height of the building: 8,91 m (9,36 m with foundation)/ 29,23 ft (30,71 ft with foundation)
- Wide of the building: 20,6 m/ 67,57 ft
- Length of the building: 16,6 m/ 54,45 ft
- Minimum plot width: 28,6 m/ 93,81 ft
- Minimum plot length: 26,75 m/ 87,74 ft
- Height of rooms: 2,8 m/ 9,18 ft
Materials:
• Foundations - concrete benches, walls of concrete blocks
• External walls - bilayer: porotherm + polystyrene
• Internal walls – porotherm
• Ceiling – Teriva
• Roof – tile
• Elevation - thin-layer plaster
The costs of implementing:
| The raw state open | 71 300,00 EUR |
| The raw state closed | 110 000,00 EUR |
| The cost of finishing works | 98 700,00 EUR |
| Execution of turnkey home | 208 700,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Ash tree - detailed file
House plan Ash tree - detailed file - mirror
