Usable area: 202.11 m2 / The cost of the realization: 182 100 EUR
Show mirror image
Price: 1180 EUR
Description
Plans
Elevations
Situations
Animation Variants (1)
Realizations (12) Detailed drawings
List of materials
Comments (3)
This house plan is an enlarged version of the house Comfortable. But it has a more extensive plan of a ground floor and a large attic that can be used as an usable attic. The building consists of two parts: a day - with a hall, living room, dining room and kitchen - forming undivided whole, and a night part - with parents' bedroom, office, two children’s bedrooms and a bath room. Each bedroom has its own dressing room, master bedroom has a private bathroom. Some part of the house is separated by a garage and storage rooms. Attic can be adapted for additional rooms. A house is designed on L-shaped - so that terraces, glazed and arcade formed an interior patio. Comfortable 2 is a large, spacious house, which will provide the perfect place to live for 4-5 person family. We also have this house plan in a mirror version.
Specifications:
- Cubature: 915 m3 / 32308,65 ft3
- Built-up area: 279,07 m2 / 3002,79 ft2
- Total area: 347,31 m2 / 3737,06 ft2
- Net area: 236,29 m2 / 2542,48 ft2
- Usable area: 202,11 m2 + garage + attic / 2174,70 ft + garage + attic
- Roof area: 383,8 m2 / 4129,69 ft2
- Roof slope: 30 degrees
- Height of the building: 6,64 m (6,94 m with foundation) / 21,78 ft (22,76 ft with foundation)
- Wide of the building: 18,09 m / 59,34 ft
- Length of the building: 21,92 m / 7190 ft
- Minimum plot width: 26,09 m / 85,57 ft
- Minimum plot length: 29,92 m / 98,14 ft
- Height of rooms: 2,70 m / 8,86 ft
Materials:
- Foundations - concrete
- Walls - bilayer: aerated concrete + polystyrene or mineral wool
- Ceiling - Teriva
- Roof - ceramic tile
The costs of implementing:
| The raw state open | 61 600,00 EUR |
| The raw state closed | 95 800,00 EUR |
| The cost of finishing works | 86 400,00 EUR |
| Execution of turnkey home | 182 100,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Comfortable 2 - detailed file
House plan Comfortable 2 - detailed file - mirror
