Anna house plan

Usable area: 82.83 m2   /   The cost of the realization: 72 100 EUR
House plan Anna - front visualization
Show mirror image

Anna house plan is a response to the need of a comfortable storeyed house. Who would not prefer to live in such a pearl instead of the three rooms in the block? Anna is a nice house with functional attic for a family of 3 - 4 people. His unpretentious architecture easily fit in with any surroundings. Simple modern architectural form built on a rectangular plan, a gable symmetrical roof, gives a sense of order and harmony. Thanks to the simple body of building the construction of the house is easy and inexpensive to build. Modern finishing materials and wall Elevation of the facade was diversified by the entrance arcade. The garden elevation is decorated with wooden pergola above a terrace available from the living room. The interior of the house as a small usable area is very spacious. There is on the ground floor: living area with lounge, kitchen, lobby with comfortable stairs, and an additional room (bedroom or study), bathroom and boiler (gas, which can be also a solid fuel stove). While at the attic there are three comfortable bedrooms with private bathroom. Thus, as a house with a usable area of 82 m2, Anna is a very functionally house plan. This is not the end of the advantages of the project. The house is very well insulated, and the modern systems and technologies make it energy efficient and cheap to future exploitation. The cost of building is very reasonable, because Anna has a simple structure and the correct ratio to the cubature to the amount of the external partitions. This is a perfect home for the frugal and conscious investors who are planning their future house tailored-made to his/her possibilities and actual needs. This house plan is a version without the garage, but it is very easy to design and build one or two cars garage to side elevation. There is a mirror version of this house plan.

  • Cubature: 368 m3/ 12994,08 ft3
  • Built-up area: 64,55 m2 (with arcades 65,70 m2)/ 694,56 ft2 (with arcades 706,93 ft2)
  • Total area: 108,04 m2/ 1162,51 ft2
  • Net area: 85,61 m2/ 921,16 ft2
  • Usable area:
    • 82,83 m2 by PN-70/B-02365 /  891,25 ft2 by PN-70/B-02365
    • 85,61 m2 by PN-ISO 9836:1997 / 921,16 ft2 by PN-ISO 9836:1997
  • Roof area: 116,09 m2/ 1249,13 ft2
  • Roof slope: 40 degrees
  • Height of the building: 7,55 m (7,75 m with foundation) / 24,76 ft ( 25,42 ft with foundation)
  • Wide of the building: 9,00 m / 29,52 ft
  • Length of the building: 7,30 m / 23,94 ft
  • Minimum plot width: 16,10 m / 52,80 ft
  • Minimum plot length: 16,11 m / 52,84 ft
  • Height of rooms: 2,6 m / 8,52 ft

• Foundations - Concrete benches and foundation walls of concrete blocks
• Walls - brick walls - porotherm 25 blocks + polystyrene + thin-layer plaster
• Ceiling -  monolithic reinforced concrete
• Elevation - thin-layer plaster on polystyrene
• Roof -  tile


The costs of implementing:
The raw state open 23 400,00 EUR
The raw state closed 36 000,00 EUR
The cost of finishing works 36 100,00 EUR
Execution of turnkey home 72 100,00 EUR

Net notified costs, do not include VAT

To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.

House plan Anna - detailed file

House plan Anna - detailed file - mirror

Anna house plan 5351 G.B i Z.B
2014.03.01 0 Pozytywny komentarz Negatywny komentarz

Despite the small area this house has a number of functions and is very nice. I have just order this house plan.

Anna house plan 4750 A.s
2013.11.04 2 Pozytywny komentarz Negatywny komentarz

I decided on this house and in the spring of next year we start its building. I would be grateful for any information for people how already built it up.

Anna house plan 4299 Madonna_45A
2013.07.21 4 Pozytywny komentarz Negatywny komentarz

Nice house plan, we really like it, I just order it and we will not make any changes.
