Usable area: 87.6 m2 / The cost of the realization: 64 400 EUR
Show mirror image
Price: 870 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Detailed drawings
List of materials
Comments (3)
Wild strawberry house plan is a charming house for family of three-four people, which could serve both as a residential house for year-round living and holiday house. The building is covered by gable roof with small decorative dormers. Access to the house is accentuated by the roof supported by wooden small columns. From the living room we go out by pretty glass doors to a large central patio. Proper proportions and human scale of the block immediately makes you want to live in this house. The interior of this house is very functional. On the ground floor there is living area, in the attic bedrooms. At the bottom we have the undivided interior of combined living room, kitchen and hall - together more than 40 m2, which, with the size of the house is a very nice surface. We enter the house through a convenient vestibule, on the side there is a toilet, and under the upper course of the stairs - bay for condensing gas boiler. In the living room nicely combined stairs to the attic with fireplace-TV wall. In the attic you will find three bedrooms with comfortable wardrobes and bathroom. All rooms are very well lighted. Wild strawberry is a small villa with a simple design, easy to build and cheap to future exploitation. Perfect for the first nest for a young family with children. Compact external dimensions permit to build it, even on a small plot. Any subsequent resale of such a house should be no problem - its functionality, unpretentious style will certainly like many people. There is also available mirror version of this house plan.
Specifications:
- Cubature: 367 m3 / 12958,77 ft3
- Built-up area: 63,28 m2 (with arcades: 69,15 m2) / 680,89 ft2 (with arcades: 744,05 ft2)
- Total area: 110,61 m2 / 1190,16 ft2
- Net area: 87,60 m2 / 942,58 ft2
-
Usable area:
- 87,60 m2 wg PN-70/B-02365 / 942,58 ft2 wg PN-70/B-02365
- 87,60 m2 wg PN-ISO 9836:1997 / 942,58 ft2 wg PN-ISO 9836:1997
- Roof area: 137,80 m2 / 1482,73 ft2
- Roof slope: 45 degrees
- Height of the building: 7,62 m (7,94 m with foundation) / 24,99 ft (26,04 ft with foundation)
- Wide of the building: 8,74 m / 28,67 ft
- Length of the building: 7,24 m / 23,75 ft
- Minimum plot width: 16,74 m / 54,91 ft
- Minimum plot length: 16,11 m / 52,84 ft
- Height of rooms 2,6 i 2,5 m / 8,53 and 8,2 ft
Materials:
- Foundations - concrete bench and foundation walls with concrete blocks
- External walls – brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
- Ceiling - Teriva
- Roof - tile
- Elevation - thin-layer plaster on polystyrene
The costs of implementing:
| The raw state open | 21 300,00 EUR |
| The raw state closed | 33 700,00 EUR |
| The cost of finishing works | 30 800,00 EUR |
| Execution of turnkey home | 64 400,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Wild strawberry - detailed file
House plan Wild strawberry - detailed file - mirror
