D05 with garage house plan

Usable area: 109.01 m2   /   The cost of the realization: 105 600 EUR
House plan D05 with garage - front visualization
Show mirror image


D05 with garage is a one-storey house with a garage, suitable for a family of 4-5 people. It has been designed for a difficult plot with access road on the south side. In this house you can freely adapt the attic. On the ground floor a living room partially connected to the hall and kitchen with access to the terrace with arcades was designed. Large kitchen with dining area opens to a space in front of the house by a glazed bay window. The boiler room is available from the porch and has a separate outside exit. Utility room next to the kitchen can be used as a laundry room or pantry. There is also a mirror versions of the D05 with a garage.

Specifications:
  • Cubature: 490 m3/ 17301,9 ft3
  • Built-up area: 166,47 m2/ 1791,22 ft2
  • Total area: 166,47 m2/ 1791,22 ft2
  • Net area: 136,58 m2/ 1469,60 ft2
  • Usable area: 109,01 m2/ 1172,95 ft2
  • Roof area: 248,61 m2/ 2675,04 ft2
  • Roof slope: 24 degrees
  • Height of the building: 5,75 m (6,07 m with foundation)/ 18,86 ft (19,91 ft with foundation)
  • Wide of the building: 18,94 m / 61,12 ft
  • Length of the building: 9,66 m / 31,68 ft
  • Minimum plot width: 25,94 m / 85,08 ft
  • Minimum plot length: 18,46 m / 60,55 ft
  • Height of rooms: 2,60 m / 8,53 ft
Materials:

• Foundations - concrete
• Foundations - reinforced concrete
• Exterior walls - aerated concrete blocks + polystyrene
• Ceiling - wooden or truss girders
• Elevation - thin-layer plaster
• Roof - ceramic tile, steel tile




The costs of implementing:
The raw state open 32 500,00 EUR
The raw state closed 51 200,00 EUR
The cost of finishing works 54 500,00 EUR
Execution of turnkey home 105 600,00 EUR

Net notified costs, do not include VAT



To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.



House plan D05 with garage - detailed file - mirror

House plan D05 with garage - detailed file

Comment
D05 with garage house plan 1251 Honney_R
2012.03.01 1 Pozytywny komentarz Negatywny komentarz

I must admit that despite the small area the house has a lot of functions. For me, a very shapely and interesting house plan.

D05 with garage house plan 1254 Marco99
2012.03.01 1 Pozytywny komentarz Negatywny komentarz

This is a hit project. I appeal to people who have already built it or are during the building of the opportunity to see it in live. Thank you in advance!

D05 with garage house plan 159 intensitea
2012.02.01 1 Pozytywny komentarz Negatywny komentarz

We decided on this house plan together with my husband. In the spring of next year we start its building. To choose this project encouraged us the architecture of this house (we really like), and secondly, we have a small plot.
