Usable area: 115.23 m2 / The cost of the realization: 91 600 EUR
Show mirror image
Price: 870 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Realizations (4) Detailed drawings
List of materials
Comments (3)
Goldfinch house plan is a detached house with a usable attic. Goldfinch house can be use as a family year-round house or as summer house. The rectangular block was covered with a gable roof of the attic. To the main body of the house the garden arcade with access from the living room and arcade - entrance porch was added. The house is ideal for a plot with an entrance from the south or west - where the garden and entrance are on the same side of the house. Goldfinch house has a simple construction - is easy and inexpensive to build. Inside, on the ground floor was planned living room with dining area, open kitchen - connected with utility room, a bathroom with a toilet and two rooms that can be used as bedrooms, or for example as a study rooms. In the attic were designed two bedrooms and a bathroom. Attic can be finished in the second stage of construction. There is also available mirror version of this house plan.
Specifications:
- Cubature: 426 m3 / 15042,06 ft3
- Built-up area: 100,5 m2 / 1081,38 ft2
- Total area: 147,45 m2 / 1586,56 ft2
- Net area: 122,4 m2 / 1317,02 ft2
- Usable area: 115,23 m2 / 1239,87 ft2
- Roof area: 186,46 m2 / 2006,31 ft2
- Roof slope: 35 degrees
- Height of the building: 6,08 m (6,38 m with foundation) / 19,94 ft (20,93 ftwith foundation)
- Wide of the building: 15 m / 49,2 ft
- Length of the building: 6,7 m / 21,98 ft
- Minimum plot width: 23 m / 75,44 ft
- Minimum plot length: 17,55 m / 57,56 ft
- Height of rooms: 2,6 m / 8,53 ft
Materials:
- Foundations – poured concrete
- External walls – brick walls - aerated concrete + polystyrene or mineral wool
- Ceiling - wooden beams
- Roof - tile or meatal roofing tile
- Elevation - thin-layer plaster
The costs of implementing:
| The raw state open | 27 600,00 EUR |
| The raw state closed | 42 400,00 EUR |
| The cost of finishing works | 49 200,00 EUR |
| Execution of turnkey home | 91 600,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Goldfinch - detailed file
House plan Goldfinch - detailed file - mirror
