Gap house plan

Usable area: 149.15 m2   /   The cost of the realization: 133 700 EUR
House plan Luka - front visualization
Show mirror image

Gap House plan is a lovely detached house for a family of four to six people. This is bungalow with usable attic, covered by an envelope roof, with garage. The block was based on a square plan, accompanied part of the garage. Envelope roof dotted with dormers - the front of the roof over the entrance, supported by two columns, and a garden with a walker. From the garden side two additional shelters was designed: over the terrace, covering exit from the living room to the garden, and the technical - at the exit from the utility room to the garden. Gap home architecture is a combination of tradition and modernity. The house will fit perfectly in every neighborhood. Interior is divided into living part and utility rooms on the ground floor and bedrooms on the top floor. Living room with hall and partly open kitchen with pantry form undivided day space. On the ground floor also two additional rooms was designed – it is an exception in this size of houses. Rooms can serve as a study or guest bedroom, but they can also be grandmother room. At the bottom there is a large garage and boiler room. In the attic there are three bedrooms - two for children of the same size, with a shared bathroom, and a comfortable master bedroom overlooking the garden with balcony, walk-in closet and bathroom. This is a very practical house, with plenty of rooms, with great potential of interior design, the building of simple construction, energy-efficient, inexpensive in build and subsequent use. There is also available a mirror version of this house plan.

  • Cubature: 789 m3 / 27859,59 ft3
  • Built-up area: 138,68 m2 / 1492,20 ft2
  • Total area: 234,51 m2 / 2523,33 ft2
  • Net area: 155,67 m2 + garage+ attic / 1675,01 ft2 + garage+ attic
  • Usable area: 149,15 m2 / 1604,85 ft2
  • Roof area: 250,69 m2 / 2697,42 ft2
  • Roof slope: 40 degrees
  • Height of the building: 8,79 m (9,09 m with foundation) / 28,83 ft (29,82 ft with foundation)
  • Wide of the building: 14,07 m / 46,15 ft
  • Length of the building: 10,34 m / 33,92 ft
  • Minimum plot width: 21,64 m / 70,98 ft
  • Minimum plot length: 18,71 m / 61,37 ft
  • Height of rooms: 2,65 m / 8,69 ft
  • Foundations - concrete bench and foundation walls with concrete blocks
  • External walls –  brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
  • Ceiling -  Teriva
  • Roof - tile
  • Elevation - thin-layer plaster on polystyrene



The costs of implementing:
The raw state open 47 700,00 EUR
The raw state closed 68 400,00 EUR
The cost of finishing works 65 400,00 EUR
Execution of turnkey home 133 700,00 EUR

Net notified costs, do not include VAT

To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.

House plan Luka - detailed file

House plan Luka - detailed file - mirror

Gap house plan 4886 mrówa
2013.12.08 0 Pozytywny komentarz Negatywny komentarz

I'd love to see the photos of this house plan! Please, can you insert it or give a link to photos.

Gap house plan 1827 Tokarska Bożena
2012.03.13 0 Pozytywny komentarz Negatywny komentarz

The house solid looks awesome. The house is spacious and functional layout of rooms is great for me.

Gap house plan 1826 Wiechowska Grażyna
2012.03.01 0 Pozytywny komentarz Negatywny komentarz

Nice house plan, we really like it, we will not make any changes.
