Nightingale house plan

Usable area: 111.04 m² / The cost of the realization: 82 000 EUR

House plan Nightingale - front visualization

Show mirror image

Price: 830 EUR

Description Plans Elevations Situations Animation Variants (0) Detailed drawings List of materials Comments (3)

Nightingale is a one-storey building with usable attic. This is house suitable for a family of 4 to 5 people, which could serve as a year-round house and summer house. House is charming, thanks to interesting details and has in fact a fairly simple layout. Building, due to the simple structure is easy to build, what would reflect positively to investment costs. Nightingale was created in a wooden frame technology. Elevation of the house is timbered with planks, but you can also do it as a plaster. Thanks to compact design house perfectly fit into the narrow plot. On the ground floor a single space of living area, with a living room, a hall and a partially open kitchen was designed. From the living room by wide doors we go out to the partially covered terrace. Next to the atrium is boiler room. In the attic there are three bedrooms and a bathroom. Nightingale house is also available in the mirror version.

Specifications:

Cubature: 406 m³ / 14335,86 ft³
Built-up area: 87,55 m²/ 942,04 ft²
Total area: 138,57 m² / 1491,01 ft²
Net area: 119,21 m² / 1282,70 ft²
Usable area: 111,04 m² / 1194,79 ft²
Roof area: 153,83 m² / 1655,21 ft²
Roof slope: 42 degrees
Height of the building: 7,41 m (7,64 m with foundation) / 24,30 ft (25,06 ft with foundation)
Wide of the building: 7,48 m / 24,53 ft
Length of the building: 11,68 m / 38,31 ft
Minimum plot width: 14,48 m / 47,49 ft
Minimum plot length: 21,08 m / 69,14 ft
Height of rooms: 2,57 i 2,50 m / 8,43 and 8,2 ft

Materials:

Foundations – poured concrete
External walls – wooden skeleton + mineral wool insulation + plank
Ceiling - wooden beams
Roof - meatal roofing tile
Elevation - plank

The costs of implementing:

The raw state open	24 000,00 EUR
The raw state closed	35 800,00 EUR
The cost of finishing works	46 200,00 EUR
Execution of turnkey home	82 000,00 EUR

Net notified costs, do not include VAT

Order

Additions to the project:

Energy-saving package free

Ventilation and fireplace package 90,00 EUR

Central vacuum package 70,00 EUR

The electronic version of the project 120,00 EUR

Solar installation package 70,00 EUR

Underfloor heating package 80,00 EUR

Heat pump package 70,00 EUR

Water jacket package 70,00 EUR

Boiler for solid fuel package 80,00 EUR

Air conditioning package 80,00 EUR

Fencing projects 140,00 EUR

Septic tanks sealed package free

Projekt domu Słowik - zestawienie materiałowe

To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.

House plan Nightingale - detailed file

House plan Nightingale - detailed file - mirror
