Usable area: 86.83 m2 / The cost of the realization: 69 400 EUR
Show mirror image
Price: 830 EUR
Description
Plans
Elevations
Situations
Animation Variants (5)
Realizations (4) Detailed drawings
List of materials
Comments (3)
Coppice is a project of a small and economic house from wooden logs. The interior of the house is formed with a division into a general part, living area - living room and private, night part with three bedrooms and a bathroom. It can be treated as a single-family house as well as a summer house. Coppice house is also available in a mirror version as well as in a variant version with the usable attic.
Specifications:
- Cubature: 430 m3 / 15183,3 ft3
- Built-up area: 107,79 m2 (+ terrace and shed) / 1159,82 ft2 (+ terrace and shed)
- Total area: 107,79 m2 / 1159,82 ft2
- Net area: 92,35 m2 / 993,69 ft2
- Usable area: 86,83 m2 / 934,29 ft2
- Roof area: 230 m2 / 2474,80 ft3
- Roof slope: 30 degrees
- Height of the building: 6,17 m (6,47 m with foundation) / 20,24 ft (21,22 ft with foundation)
- Wide of the building: 13,08 m / 42,90 ft
- Length of the building: 10,00 m / 32,8 ft
- Minimum plot width: 21,08 m / 69,14 ft
- Minimum plot length: 22,39 m / 73,44 ft
- Height of rooms: 2,60 m / 8,53 ft
Materials:
- Foundations - poured concrete
- Exterior walls - wooden balls or aerated concrete blocks
- Internal walls - wooden balls, walls of plasterboard or aerated concrete blocks
- Ceiling - gypsum headlining suspended from the roof truss
- Roofing - bituminous tile or tinware tile
The costs of implementing:
| The raw state open | 27 800,00 EUR |
| The raw state closed | 39 600,00 EUR |
| The cost of finishing works | 29 900,00 EUR |
| Execution of turnkey home | 69 400,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Coppice - detailed file
House plan Coppice - detailed file - mirror
