Susan house plan

Usable area: 146.33 m² / The cost of the realization: 124 300 EUR

Show mirror image

Price: 1000 EUR

Description Plans Elevations Situations Animation Variants (0) Realizations (40) Detailed drawings List of materials Comments (3)

Susan is very practical and charming detached house. Perfect for a family of four to five people. This is a one-storey building with attic covered by a hipped roof, with aa garage partly embedded in the body of the house. The body is decorated with a large attic dormer, entrance with a roofing and columns, dining room bay window and garden arcade. The traditional form of Polish house has been given in a modern, fresh approach. Materials used in Susan house or large glass opening inside to the garden, functional interior layout - a whole emphasizes the modern solutions. The interior of the ground floor has been designed as an open, living area, with a lounge, hall, a dining area, and a partially open kitchen. In addition, on the ground floor is room which could serve as an office or bedroom, garage and boiler room. On the top floor there are three good-sized bedrooms with wardrobes or built in wardrobes, bathroom and an additional room. This average size house, by the functional arrangement of the interior has managed to fit a lot of space, so that the house feels larger than it actually is. Susan house plan is also available in a mirror version.

Specifications:

Cubature: 653 m³/ 23057,43 ft³
Built-up area/: 135,64 m²/ 1459,49 ft²
Total area: 216,9 m² / 2333,84 ft²
Net area: 153,1 m² / 1647,36 ft²
Usable area: 146,33 m²/ 1574,51 ft²
Roof area: 245,03 m²/ 2636,52 ft²
Roof slope: 40 degreesi/ 40 degress
Height of the building: 8,51 m (8,96 m with foundation) / 27,91 ft ( 29,38 ft with foundation)
Wide of the building: 11,36 m / 37,26 ft
Length of the building: 15,53 m / 50,94 ft
Minimum plot width: 18,38 m / 60,29 ft
Minimum plot length: 23,8 m / 78,064 ft
Height of rooms: 2,7 i 2,6 m / 8,85 and 8,53 ft

Materials:

Foundations - concrete bench and foundation walls with concrete blocks
External walls – brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
Ceiling - Teriva
Elevation - thin-layer plaster on polystyrene

Roof - tile

The costs of implementing:

The raw state open	43 600,00 EUR
The raw state closed	65 000,00 EUR
The cost of finishing works	59 300,00 EUR
Execution of turnkey home	124 300,00 EUR

Net notified costs, do not include VAT

Order

Additions to the project:

Energy-saving package free

Ventilation and fireplace package 90,00 EUR

Central vacuum package 70,00 EUR

The electronic version of the project 120,00 EUR

Solar installation package 70,00 EUR

Underfloor heating package 80,00 EUR

Heat pump package 70,00 EUR

Water jacket package 70,00 EUR

Boiler for solid fuel package 80,00 EUR

Air conditioning package 80,00 EUR

Fencing projects 140,00 EUR

Septic tanks sealed package free

House plan Zuzia - bill of materials

To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.

House plan Susan - detailed file

House plan Susan - detailed file - mirror
