Usable area: 96.61 m2 / The cost of the realization: 91 500 EUR
Show mirror image
Price: 970 EUR
Description
Plans
Elevations
Situations
Animation Variants (1)
Realizations (10) Detailed drawings
List of materials
Comments (3)
Alice house plan is a proposal for a family of 4-5 people. This is a one-storeyed house, with the usable attic, covered with a gable roofs, with the garage build on. Alice house was designed in quiet style with traditional and modern details. The compact body of building with the garage build on, was decorated with dormer windows, and a balcony in the garden elevation. Inside the house on the ground floor there is a hall connected with the living room forming an open living space. An open kitchen connects to the dining area additionally increasing the interior. Centrally located stairs leading to the attic and stack - TV partition are the main axis of the division of space. On the ground floor an extra room which can serve as a study or extra bedroom was designed. From a large bathroom with shower the technical annex with a central heating boiler was separated. There are three bedrooms and bathroom on the top floor. Alice house plan is also available in a mirror version.
Specifications:
- Cubature: 438 m3 / 15465,78 ft3
- Built-up area: 96,99 m2 / 1043,61 ft2
- Total area: 142,04 m2/ 1528,35 ft2
- Net area: 96,61 m2 + garage / 1039,52 ft2 + garage
- Usable area: 96,61 m2/ 1039,52 ft2
- Roof area: 174,41 m2/ 1876,65 ft2
- Roof slope: 45 and 20 degrees
- Height of the building: 7,76 m (8,06 m with foundation) / 25,45 ft (26,44 ft with foundation)
- Wide of the building: 10,59 m / 34,74 ft
- Length of the building: 10,04 m / 32,93 ft
- Minimum plot width: 17,59 m / 57,70 ft
- Minimum plot length: 18,04 m / 59,17 ft
- Height of rooms: 2,65 i 2,5 m / 8,69 ft and 8,2 ft
Materials:
• Foundations - concrete bench and foundation walls with concrete blocks
• External walls – brick walls - cellular concrete blocks + polystyrene + thin-layer plaster
• Ceiling - Teriva
• Elevation - thin-layer plaster on polystyrene
• Roof - tile
The costs of implementing:
| The raw state open | 30 900,00 EUR |
| The raw state closed | 45 800,00 EUR |
| The cost of finishing works | 45 800,00 EUR |
| Execution of turnkey home | 91 500,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Alice - detailed file
House plan Alice - detailed file - mirror
