Usable area: 124.73 m2 / The cost of the realization: 124 500 EUR
Show mirror image
Price: 970 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Detailed drawings
List of materials
Comments (3)
Breeze 4 house plan is a variant version of the Breeze house plan. Breeze 4, is a year-round, one-storeyed house with the usable attic, this house is perfect for a family for the 4-6 people. The simple body of building is covered by a gable roof. To the main body of building the garage part with a double garage has been build. The architecture of the house is a combination of modern materials and colors with the traditional form of the building. Thanks to this house perfect fit in any surroundings. The interior of the house is divided into a living area on the ground floor and bedrooms on the top floor. On the ground floor, besides to a living room with kitchen and hall (with stairs) an extra room - for example for a study, a comfortable bathroom, boiler room and garage for two cars, with utility room have been designed. On the top floor there are three bedrooms with the bathroom, and the attic. The attic in this house plan is treated as a no usable space, but it can be easily adapted for utility purposes. Thanks to that we will obtain one large extra room or two smaller rooms. The house has a simple construction, is easy with the building and inexpensive. Thanks to a compact body in it, you can get a good performance efficiency. Additional advantage of the building are two roofed, corner terrace this is something very useful on sunny as well as during the rainy days.
Specifications:
- Cubature: 675 m3/ 23834,25 ft3
-
Built-up area:
- with arcades 141,17 m2/ 1518,99 ft2
- without arcades 168,54 m2/ 1813,49 ft2
- Total area: 222,98 m2/ 2399,26 ft2
- Net area: 154,08 m2 + garage 32,78 m2/ 1657,90 ft2 + garage 352,71 ft2
-
Usable area:
- 124,73 m2 by PN-70/B-02365/ 1342,09 ft2 by PN-70/B-02365
- 154,08 m2 + garage by PN-ISO 9836:1997/ 1657,90 ft2 + garage by PN-ISO 9836:1997
- Roof area: 247,45 m2/ 2662,56 ft2
- Roof slope: 38 degrees
- Height of the building: 7,20 m (7,64 m with foundation) / 23,62 ft (25,06 ft with foundation)
- Wide of the building: 15,86 (17,36) m / 52,02 (59,94) ft
- Length of the building: 9,73 (11,98) m / 31,91 (39,29) ft
- Minimum plot width: 23,31 m / 76,46 ft
- Minimum plot length: 18,98 m / 62,25 ft
- Height of rooms: 2,67 m / 8,76 ft
Materials:
• Foundations - Concrete benches and foundation walls of concrete blocks
• External walls - brick walls - concrete blocks + polystyrene + thin-layer plaster
• Ceiling - Teriva
• Elevation - thin-layer plaster on polystyrene
• Roof - tile
The costs of implementing:
| The raw state open | 38 500,00 EUR |
| The raw state closed | 64 500,00 EUR |
| The cost of finishing works | 60 000,00 EUR |
| Execution of turnkey home | 124 500,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Breeze 4 - detailed file
House plan Breeze 4 - detailed file - mirror
