Usable area: 109.41 m2 / The cost of the realization: 95 900 EUR
Show mirror image
Price: 970 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Detailed drawings
List of materials
Comments (3)
Breeze 6 house plan is the next version of the popular Breeze houses. The house has a floor area less than 110 m2, so that qualifies as a house plan for most people applying for payment and participation in the program. This house plan, although a small area, have all the necessary functions. On the ground floor a nice living room with hall and kitchen, and an extra room and bathroom is designed. The boiler room was hidden in the annex in the garage, so as to reduce the usable area (this project foresees gas boiler, but it can also be a solid fuel boiler). On the top floor there are three bedrooms and bathroom. The house has a simple body and is covered by gable roof. To the main residential part a garage part is built. The house has a simple construction, is inexpensive and not complicated in construction. Thanks to energy-saving technologies will be also cheap in the later exploitation. and inexpensive in construction house. This house is a grate proposal for practical and modern-minded investors. Breeze 6 house plan is ideal proposition for a young couple with two children, for investors who respect the economy and want to build a reasonable house - convenient, comfortable, and not overdone.
Specifications:
- Cubature: 605 m3/ 21362,55 ft3
- Built-up area: 127,02 m2/ 1366,74 ft2
- Total area: 188,28 m2/ 2025,89 ft2
- Net area: 109,41 m2 + garage 29,08 m2/ 1177,25 ft2 + garage 312,90 ft2
-
Usable area:
- 109,41 m2 by PN-70/B-02365/ 1177,25 ft2 by PN-70/B-02365
- 109,41 m2 + garage by PN-ISO 9836:1997/ 1177,25 ft2 + garage by PN-ISO 9836:1997
- Roof area: 189,55 m2/ 2039,56 ft2
- Roof slope: 38 degrees
- Height of the building: 7,20 m (7,50 m with foundation) / 23,62 ft (24,60 ft with foundation)
- Wide of the building: 14,26 m / 46,77 ft
- Length of the building: 9,89 m / 32,44 ft
- Minimum plot width: 22,26 (21,26) m / 73,01 (69,73) ft
- Minimum plot length: 17,89 m / 58,68 ft
- Height of rooms: 2,65 m / 8,69 ft
Materials:
• Foundations - Concrete benches and foundation walls of concrete blocks
• External walls - brick walls - concrete blocks + polystyrene + thin-layer plaster
• Ceiling - Teriva
• Elevation - thin-layer plaster on polystyrene
• Roof - tile
The costs of implementing:
| The raw state open | 31 300,00 EUR |
| The raw state closed | 47 700,00 EUR |
| The cost of finishing works | 48 200,00 EUR |
| Execution of turnkey home | 95 900,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Breeze 6 - detailed file
House plan Breeze 6 - detailed file - mirror
