Usable area: 107.45 m2 / The cost of the realization: 87 100 EUR
Show mirror image
Price: 900 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Realizations (13) Detailed drawings
List of materials
Comments (3)
Dominik house plan is an elegant, small single-family house even for a family up to 7 people. Envelope roof, ornate entrance portico and elevation with clinker formed a successful combination. Inside the house on a small area it managed to fit a living room and five bedrooms, that is unheard in small homes. Dominik house was designed in such way that the attic can be finished in the second stage of building. Dominik house plan is also available in a mirror version.
Specifications:
- Cubature: 393 m3/ 13876,83 m2
- Built-up area: 110,42 m2/ 1188,12 ft2
- Total area: 133,33 m2/ 1434,63 ft2
- Net area: 112,81 m2/ 1213,84 ft2
-
Usable area:
- 107,45 m2 by PN-70/B-02365/ 1156,16 ft2 by PN-70/B-02365
- 110,82 m2 by PN-ISO 9836:1997/ 1192,42 ft2 by PN-ISO 9836:1997
- Roof area: 158 m2/ 1700,08 ft2
- Roof slope: 30 degrees
- Height of the building: 6,01 m (6,31 m with foundation)/ 19,71 ft (20,70 ft with foundation)
- Wide of the building: 13,24 m / 43,43 ft
- Length of the building: 8,34 m / 27,35 ft
- Minimum plot width: 20,24 m / 66,39 ft
- Minimum plot length: 16,34 m / 53,60 ft
- Height of rooms: 2,61 m / 8,56 ft
Materials:
• Foundations - Concrete
• Walls - ceramic max blocks + polystyrene
• Ceiling - Teriva
• Elevation - thin-layer plaster
• Roof – ceramic tile and metal roofing tile
The costs of implementing:
| The raw state open | 30 400,00 EUR |
| The raw state closed | 43 400,00 EUR |
| The cost of finishing works | 43 800,00 EUR |
| Execution of turnkey home | 87 100,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Dominik - detailed file
House plan Dominik - detailed file - mirror
