Ophelia 3 house plan

Usable area: 179.11 m2   /   The cost of the realization: 149 760 EUR
House plan Ophelia 3 - front visualization
Show mirror image

House plan Ophelia 3 is the next version of the popular series of houses Ophelia. The project is reduced compared to the basic version, with a single garage and with additional business premises on the ground floor: apartment for seniors or adult children, or office space. Ophelia 3 is a single family house with attic, covered with a hipped roof, with an added part of the garage. The traditional architecture of the house, the manorial body combined with modern materials and details. The whole gets the timeless character. Front of house has been accented by wide dormers with a balcony supported by columns. We enter to the house by representative wide doors. From the garden side elevation is varied by dormers with balcony, living room bay window with a beautiful window, and arcade partly roofed the terrace. The interior of house: on the ground floor there was separated living space and additional premises (apartment or office for example), to which we get from a spacious vestibule. In the living area we have a living room with dining area and hall, and a kitchen with a pantry. In addition to the house we have built another garage with a boiler room (garage part can be combined with house by additional door). In the attic three bedrooms with a large bathroom, an additional room above the garage were designed. Master bedroom has its own walk-in closet, and a balcony overlooking the garden. Ophelia 3 is a great choice for family of many generations or for investors conducting their business at home. Building has a fairly simple structure. It is easy to build, and thanks to energy-efficient solutions will be cheap in further exploitation.

  • Cubature: 862 m3/30437 ft3
  • Built-up area: 160,06 m2/1722,25 ft2
  • Total area: 256,39 m2/2758,76 ft2
  • Net area: 185,03 m2 + garage /1990,92 ft2 + garage
  • Usable area: 179,11 m2/1927,22 ft2
  • Roof area: 262,6 m2/2825,58 ft2
  • Roof slope: 40 degrees
  • Height of the building: 8,55 m (8,80 m with foundation)/28,04 ft (28,86 ft with foundation)
  • Building dimensions: 16,94 m/55,56 ft x 11,36 m/37,26 ft
  • Plot dimensions: 23,94 m/78,52 ft x 19,51 m/63,99 ft
  • Height of rooms: 2,7 & 2,5 m/8,86 & 8,20 ft
  • Foundations - concrete bench and foundation walls with concrete blocks
  • External walls – brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
  • Ceiling - Teriva
  • Elevation - thin-layer plaster on polystyrene
  • Roof - ceramic tile


The costs of implementing:
The raw state open 56 450,00 EUR
The raw state closed 86 150,00 EUR
The cost of finishing works 73 960,00 EUR
Execution of turnkey home 149 760,00 EUR

Net notified costs, do not include VAT

To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.

House plan Ophelia 3 - detail drawings

House plan Ophelia 3 - detail drawings mirror
