Seclusion house plan

Usable area: 182.32 m2   /   The cost of the realization: 156 400 EUR
House plan Zacisze - front visualization
Show mirror image


Seclusion house is a variant version of project Seclusion 2. House has been narrowed, thanks to this it fit on a smaller plot, with a width of 23 meters. Simplified block, eliminating the annex at the garage. In Seclusion house plan bay window in dining room has been converted into a large window. In Seclusion 2 several walls was removed to give a more open space - a living room, hall and dining room. There is also a mirror version of the Seclusion house plan.

Specifications:
  • Cubature: 989 m/ 34921,59 ft3
  • Built-up area: 185,69 m2 / 1998,02 ft2
  • Total area: 281,8 m2 / 3032,17 ft2
  • Net area: 233,93 m2 / 2517,09 ft2
  • Usable area: 182,32 m2 / 1961,76 ft2
  • Roof area: 285,5 m2 / 3071,98 ft2
  • Roof slope: 35 degrees
  • Height of the building: 7,90 m (8,60 m with foundation) / 25,91 ft (28,21 ft with foundation)
  • Wide of the building: 16,1 m / 52,81 ft
  • Length of the building: 13,44 m / 44,08 ft
  • Minimum plot width: 23,1 m / 75,77 ft
  • Minimum plot length: 21,44 m / 70,32 ft
  • Height of rooms: 2,80 m / 9,18 ft
Materials:
  • Foundations - concrete bench and foundation walls with concrete blocks
  • External walls – bilayer  porotherm
  • Ceiling -  Teriva
  • Roof -  tile
  • Elevation - thin-layer plaster






The costs of implementing:
The raw state open 54 300,00 EUR
The raw state closed 80 000,00 EUR
The cost of finishing works 76 500,00 EUR
Execution of turnkey home 156 400,00 EUR

Net notified costs, do not include VAT



To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.



House plan Zacisze - detailed drawings

House plan Zacisze - detailed drawings - mirror

Comment
Seclusion house plan 3130 Jolanta Dzięcioł
2012.10.07 0 Pozytywny komentarz Negatywny komentarz

The house solid looks awesome. The house is spacious and functional layout of rooms is great for me.

Seclusion house plan 2108 Lidia Rogalska
2012.03.12 0 Pozytywny komentarz Negatywny komentarz

I was looking for a simple, functional home, and reviewing the offers of various architectural studios. This house is quite ok. The area of the house and the layout of the rooms perfectly suits us. I think that will be just right for my family.

Seclusion house plan 876 jolka37
2012.02.24 0 Pozytywny komentarz Negatywny komentarz

Nice house plan, we really like it, we will not make any changes.
