Usable area: 195.13 m2 / The cost of the realization: 135 200 EUR
Show mirror image
Price: 1040 EUR
Description
Plans
Elevations
Situations
Animation Variants (3)
Realizations (6) Detailed drawings
List of materials
Comments (3)
Maja house plan is the perfect choice for a family of four to five people. The building has an attractive body with a gentle hipped roof, which is adorned a large dormer windows with balconies and an extensive entrance arcade from the garden side. On the ground floor besides a large living room and an extra room for example on study or a guest bedroom – was designed. In the part of first floor are bedrooms and a large bathroom. The attic over the garage can be used as a laundry room with drying room. We have also a version of Maja house plan with four bedrooms in the attic.
Specifications:
- Cubature: 766 m3 / 27047,46 ft3
- Built-up area: 162,5 m2 / 1748,50 ft2
- Total area: 266,5 m2 / 2867,54 ft2
- Net area: 203,57 m2 + garage / 2190,41 ft2 + garage
- Usable area: 195,13 m2 + garage + utility room / 2099,60 ft2 + garage + utility room
- Roof area: 310 m2 / 3335,60 ft2
- Roof slope: 35 and 40 degrees
- Height of the building: 7,82 m (8,29 m with foundation) / 25,65 ft (27,19 ft with foundation)
- Wide of the building: 14,98 m / 49,13 ft
- Length of the building: 14,96 m / 49,07 ft
- Minimum plot width: 22,96 m / 75,31 ft
- Minimum plot length: 22,3 m / 73,14 ft
- Height of rooms: 2,80 m / 9,18 ft
Materials:
- Foundations - poured bench+ concrete blocks
- External walls - bilayer porotherm 25 + 12 mineral wool (or polystyrene) +thin-layer plaster, or aerated concrete + polystyrene
- Ceiling - Teriva
- Elevation - thin-layer plaster
- Roof - tile or meatal roofing tile
The costs of implementing:
| The raw state open | 46 700,00 EUR |
| The raw state closed | 69 800,00 EUR |
| The cost of finishing works | 65 500,00 EUR |
| Execution of turnkey home | 135 200,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Maja - detailed file
House plan Maja - detailed file - mirror
