Usable area: 336 m2 / The cost of the realization: 232 400 EUR
Show mirror image
Price: 1760 EUR
Description
Plans
Elevations
Situations
Animation Variants (1)
Realizations (13) Detailed drawings
List of materials
Comments (3)
Falcon is a representative storey residence, giving the impression of convenience and luxury. The building is covered by hipped roof, with many decorative elements. The interior of the building is designed around a large hall with elegant staircase. Entrance part is a hall with cloakroom and pantry on the sides, providing direct access to the garage and the kitchen. The living area is enriched with office-library and a recreation room. In the bathroom you can put sauna. Since the villa Falcon is earmarked for a large family on the first floor is designed five rooms, including parents' bedroom with separate bathroom and dressing room. From the first floor you can get to the attic by staircase, which can be alternatively converted into a single space studio. All this creates a harmonious whole. Despite no small dimensions house is located on a relatively small plot. There is also a mirror version of the Falcon house plan.
Specifications:
- Cubature: 1344 m3 / 47456,64 ft3
- Built-up area: 248,64 m2 (with arcades: 263,19 m2) / 2675,37 ft2 (with arcades: 2831,92 ft2)
- Total area: 455,58 m2 / 4902,04 ft2
- Net area: 344,61 m2 + garage34,42 m2 / 3708,00 ft2 + garage 370,36 ft2
-
Usable area:
- 336,00 m2 (wg PN-70/B-02365) / 3615,36 ft2 (wg PN-70/B-02365)
- 344,61 m2 + garage 34,42 m2 (wg PN-ISO 9836:1997) / 3708,00 ft2 + garage 370,36 ft2 (wg PN-ISO 9836:1997)
- Roof area: 267,65 m2 / 2879,91 ft2
- Roof slope: 30 degrees
- Height of the building: 10,24 m (10,54 m with foundation) / 33,59 ft (34,57 ft with foundation)
- Wide of the building: 17,72 m / 58,12 ft
- Length of the building: 17,11 m / 56,12 ft
- Minimum plot width: 24,72 m / 81,08 ft
- Minimum plot length: 25,11 m / 82,36 ft
- Height of rooms: 3 m / 9,84 ft
Materials:
- Foundations - concrete bench
- External walls – porotherm + insulation
- Internal walls - porotherm
- Ceiling - monolithic reinforced concrete
- Roof - tile
The costs of implementing:
| The raw state open | 76 700,00 EUR |
| The raw state closed | 109 300,00 EUR |
| The cost of finishing works | 123 200,00 EUR |
| Execution of turnkey home | 232 400,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Falcon - detailed file - mirror
House plan Falcon - detailed file
