Usable area: 127.12 m2 / The cost of the realization: 121 500 EUR
Show mirror image
Price: 900 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Detailed drawings
List of materials
Comments (3)
Solid is a one-storey house with attic. Suitable for a family of 4 to 5 people. The building has a compact body, and is covered by a gable roof with pediments, and built it has added on the front a garage. On the ground floor, besides a living room with a fireplace and a dining room with a bay designed an extra room and bathroom. In Solid house on the attic there are three bedrooms with bathroom and dressing room. Attic over garage can be used for laundry -drying room or magazine available from the garage. This house is ideal for a narrow plot. There is also a mirror version of the Solid house plan.
Specifications:
- Cubature: 683 m3 / 24116,73 ft3
- Built-up area: 132,22 m2 / 1422,69 ft2
- Total area: 216,74 m2 / 2332,12 ft2
- Net area: 136,2 m2 + garage / 1465,51 ft2 + garage
- Usable area: 127,12 m2 + garage+ attic / 1367,81 ft2 + garage+ attic
- Roof area: 228,6 m2 / 2459,74 ft2
- Roof slope: 42 degrees
- Height of the building: 8,58 m (8,85 m with foundation) / 28,14 ft (29,02 ft with foundation)
- Wide of the building: 10,18 m / 33,39 ft
- Length of the building: 17,02 m / 55,83 ft
- Minimum plot width: 18,18 m / 59,63 ft
- Minimum plot length: 25,02 m / 82,07 ft
- Height of rooms: 2,60 m / 8,53 ft
Materials:
- Foundations – concrete
- External walls - bilayer ceramic bricks + mineral wool
- Ceiling - Teriva
- Roof - ceramic tile
The costs of implementing:
| The raw state open | 41 200,00 EUR |
| The raw state closed | 62 000,00 EUR |
| The cost of finishing works | 59 600,00 EUR |
| Execution of turnkey home | 121 500,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Solid - detailed file
House plan Solid - detailed file - mirror
