Artemis house plan

Usable area: 129.48 m2   /   The cost of the realization: 118 200 EUR
House plan Artemis- rear visualization
Show mirror image

Artemis house plan is a small, storey house for a family of 3 - 4 people, with a compact, simple in building shape and modern architecture. Artemis house is designed in a square and covered by a hipped, envelope roof. Slightly protruding garage with the entrance arcade roof over the terrace garden, wall Elevation around the windows - all these elements diversified the silhouette giving it an attractive appearance. The interior of Artemis house is divided into living and utility part on the ground floor, and bedrooms on the upper floor. Living room was combined with a dining, hall, the prominence stairs and open kitchen creating a living space. In the Artemis house plan the garage is available from the atrium and together with a large boiler room create the utility part. Three comfortable bedrooms upstairs with wardrobe, the master bedroom, and a bathroom with laundry facilities creates the night part of the house. The house although the small size, includes all the necessary facilities. The rooms are spacious, and thanks the top floor there are no bevels. Above the top floor there is an attic possible to adaptations. There is also a mirror version of this house plan.

  • Cubature: 732 m3/ 25846,92 ft2
  • Built-up area: 110,21 m2/ 1185,86 ft2
  • Total area: 205,12 m2/ 2207,09 ft2
  • Net area: 136,83 m2 + garage / 1472,29 ft2+ garage
  • Usable area: 129,48 m2/ 1393,20 ft2
  • Roof area: 145,98 m2/ 1570,74 ft2
  • Roof slope: 30 degrees
  • Height of the building: 8,85 m (9,00 m with foundation) / 29,03 ft ( 29,52 ft with foundation)
  • Wide of the building: 10,08 m / 33,06 ft
  • Length of the building: 12,06 m / 39,56 ft
  • Minimum plot width: 17,98 m / 58,97 ft
  • Minimum plot length: 20,76 m / 68,09 ft
  • Height of rooms:  2,6 m / 8,52 ft

• Foundations - Concrete benches and foundation walls of concrete blocks
• Walls - brick walls - porotherm 25  blocks + polystyrene + thin-layer plaster
• Ceiling -  Teriva
• Elevation - thin-layer plaster on polystyrene
• Roof -  tile



The costs of implementing:
The raw state open 43 900,00 EUR
The raw state closed 60 500,00 EUR
The cost of finishing works 57 800,00 EUR
Execution of turnkey home 118 200,00 EUR

Net notified costs, do not include VAT

To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.

House plan Artemis - detailed file - mirror

House plan Artemis - detailed file

Artemis house plan 1412 RomG
2012.02.28 1 Pozytywny komentarz Negatywny komentarz

Very cool interior layout of this house is the main advantages. I think it would be great for our family.

Artemis house plan 1413 miss_zoo
2012.02.19 1 Pozytywny komentarz Negatywny komentarz

This is the best project. I like it very much and want to buy it soon!

Artemis house plan 80 pamel_W
2012.01.31 9 Pozytywny komentarz Negatywny komentarz

I was looking for a simple, functional home, and reviewing the offers of various architectural studios. This house is quite ok. The area of the house and the layout of the rooms perfectly suits us. I think that will be just right for my family.
