Amethyst house plan

Usable area: 139.98 m2   /   The cost of the realization: 119 800 EUR
House plan Amethyst - front visualization
Show mirror image

Amethyst house plan is a single-family house for a family of 4 – 6 people. This house was covered by the hipped roof. Compact, simple in building body of the building with the build garage, was varied by the clinker on facade and arcades - the entrance and garden. In this house plan a particular emphasis was put on the purity and simplicity of building form. Frugal detail adds elegance to the house. The interior of the house was also planned so that the divisions of the rooms were clear – no needless corridors and the rooms themselves have an optimal shape. On the ground floor a living room with dining area and lobby, with a partially open kitchen and an extra room - study or guest bedroom was designed. On the first floor there are three bedrooms with dressing-room and built-in wardrobes and a large bathroom. It is also a possible to save up additional fourth room on the first floor – by eliminating wardrobe. There is also a mirror version of Amethyst.

  • Cubature: 659 m3/ 23269,29 ft3
  • Built-up area: 122,7 m2/ 1320,25 ft2
  • Total area: 218,3 m2/ 2348,91 ft2
  • Net area: 149,98 m2 + garage / 1613,78 ft2 + garage
  • Usable area: 139,98 m2 / 1506,18 ft2
  • Roof area: 198,46 m2/ 2135,43 ft2
  • Roof slope: 30 degrees
  • Height of the building: 8,67 m (8,97 m with foundation) / 28,44 ft ( 29,42 ft with foundation)
  • Wide of the building: 11,95 m / 39,20 ft
  • Length of the building: 12,82 m / 42,05 ft
  • Minimum plot width: 18,95 m / 62,16 ft
  • Minimum plot length: 20,82 m / 68,29 ft
  • Height of rooms: 2,7 i 2,6 m / 8,86 ft and 8,53 ft

• Foundations - Concrete benches and foundation walls of concrete blocks
• Walls - brick walls - porotherm 25 blocks + polystyrene + thin-layer plaster
• Ceiling -  Teriva
• Elevation - thin-layer plaster on polystyrene
• Roof -  tile


The costs of implementing:
The raw state open 40 100,00 EUR
The raw state closed 60 100,00 EUR
The cost of finishing works 59 800,00 EUR
Execution of turnkey home 119 800,00 EUR

Net notified costs, do not include VAT

To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.

House plan Amethyst - detailed file

House plan Amethyst - detailed file -mirror
