Maja 2 house plan

Usable area: 208.13 m2   /   The cost of the realization: 153 700 EUR
House plan Maja 2 - front visualization
Show mirror image


May 2 house plan is a variant version of Maja house plan. From the basic design differs double garage and enlarged utility room, so useful at home. External aesthetics of this version has also been changed. It refers to the trendy lately style full of charm, at the same time gave the impression of solidity and harmony homes for the middle class. Spacious and comfortable interior is well thought out and hides all the necessary functions, however, it was scheduled for a reasonable surface. Maja 2 house plan is also available in mirror version.

Specifications:
  • Cubature: 843,8 m3 / 29794,58 ft3
  • Built-up area: 183,9 m2 / 1978,76 ft2
  • Total area: 294,2 m2 / 3165,59 ft2
  • Net area: 216,57 m2 + garage / 2330,29 ft2 + garage
  • Usable area: 208,13 m2 + garage + utility room / 2239,48 ft2 + garage + utility room
  • Roof area: 341 m2 / 3669,16 ft2
  • Roof slope: 35 and 40 degrees
  • Height of the building: 7,82 m (8,29 m with foundation) / 25,65 ft (27,19 ft with foundation)
  • Wide of the building: 16,98 m / 55,69 ft
  • Length of the building: 14,96 m / 49,07 ft
  • Minimum plot width: 24,28 m / 79,64 ft
  • Minimum plot length: 22,96 m / 75,31 ft
  • Height of rooms: 2,80 m / 9,18 ft
Materials:
  • Foundations –  concrete
  • External walls - bilayer: max or porotherm + mineral wool (or polystyrene)
  • Ceiling -  Teriva
  • Roof -  tile or meatal roofing tile






The costs of implementing:
The raw state open 52 800,00 EUR
The raw state closed 80 900,00 EUR
The cost of finishing works 72 800,00 EUR
Execution of turnkey home 153 700,00 EUR

Net notified costs, do not include VAT



To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.



House plan Maja 2 - detailed file

House plan Maja 2 - detailed file - mirror

Comment
Maja 2 house plan 1875 Misia_O
2012.03.14 0 Pozytywny komentarz Negatywny komentarz

Very cool interior layout of this house is the main advantages. I think it would be great for our family. I look forward to shipment and thank you for your kind support.

Maja 2 house plan 1880 Klarysa
2012.02.28 0 Pozytywny komentarz Negatywny komentarz

I was looking for a simple, functional home, and reviewing the offers of various architectural studios. This house is quite ok. The area of the house and the layout of the rooms perfectly suits us. I think that will be just right for my family.

Maja 2 house plan 494 erka-555
2012.02.08 3 Pozytywny komentarz Negatywny komentarz

Nice house plan, we really like it, we will not make any changes.
