Riviera 5 house plan

Usable area: 197.1 m2   /   The cost of the realization: 174 640 EUR
House plan Riviera 5 - front visualization
Show mirror image


Riviera 5 house plan is next variant version of popular house plan Riviera - this time without basement, with roof of higher angle, and with a variant version of interior: with emptiness and a entresol above the living room, and without emptiness. This story house, built in a "T" letter with a protruding slightly to the front part of the garage. It is covered by hipped tile roof. Modern block was decorated with large windows, stone wall claddings, rustications and cornices separating the ground floor and first floor. Particularly spectacular are corner windows in the living area connected to the first floor windows. The architecture of the house is modern, at the same time restrained, toned down and not exaggerated. As a result, the building does not lose its coziness. Thanks to the arrangement of the interior and the appropriate location of windows can be placed on the property with entrance from the south. Interior: on the ground floor there was design an open space daily - in the version with emptiness above the living room. Kitchen with island separated from the lobby by decoration glass wall of living room. Living room, dining room and lobby together form a beautiful interior. On the ground floor we have an extra room (study or guest bedroom), a toilet, a boiler room and a garage for two cars. On the floor, depending on the version (with or without emptiness) we have three or four bedrooms, 2 bathrooms, dressing rooms and a laundry. Parents' bedroom is a separate apartment with bathroom and two dressing rooms. In the version with emptiness above the living room we have a beautiful entresol which is a continuation of the living room. House plan Riviera 5 - front visualization - mirror version is an attractive, modern house, with energy-efficient solutions.

Specifications:
  • Cubature: 945 m3/33367,95 ft3
  • Built-up area: 162,46 m2/1748,07 ft2
  • Total area: 302,14 m2/3251,03 ft2
  • Net area: 204,51 m2 + garage /2200,53 ft2 + garage
  • Usable area: 197,06 m2/2120,37 ft2
  • Roof area: 258,65 m2/2783,07 ft2
  • Roof slope: 30 degrees
  • Height of the building: 9,24 m (9,49 m with foundation)/30,31 ft (31,13 ft with foundation)
  • Building dimensions: 13,15 m/43,13 ft x 16,08 m/52,74 ft
  • Plot dimensions: 20,05 m/65,76 ft x 24,08 m/78,98 ft
  • Height of rooms: 2,8 & 2,6 m/9,18 & 8,53 ft
Materials:
  • Foundations - concrete bench and foundation walls with concrete blocks
  • External walls – brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
  • Ceiling - Teriva
  • Elevation - thin-layer plaster on polystyrene
  • Roof - ceramic tile




The costs of implementing:
The raw state open 58 670,00 EUR
The raw state closed 82 460,00 EUR
The cost of finishing works 92 190,00 EUR
Execution of turnkey home 174 640,00 EUR

Net notified costs, do not include VAT



To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.



House plan Riviera 5 - detailed drawings

House plan Riviera 5 - detailed drawings - mirror
