Usable area: 185.42 m2 / The cost of the realization: 184 100 EUR
Show mirror image
Price: 1140 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Realizations (6) Detailed drawings
List of materials
Comments (3)
Vega house plan is storey detached house for a family of four-five people, covered by envelope roof. Vega is an urban villa, characterized by a modern but restrained architecture. Building was designed for the a small plot where you can build over small area and body of the house must be as compact. In the basement was hidden technical rooms, so all daily space can take the whole ground floor - outside garage was built into the body of the house. Rooms and its lighting were designed in such a way that the house also fit to plot with entrance from the south. Interior of building is divided into single, daily space on the ground floor, with an extra room - office or a guest bedroom, and night space on the first floor, with bedrooms and a large family bathroom. From extensive lobby you can extract additional small little room. Above the first floor is a single space of attic that could serve as an extra room. Vega house is open to the garden. From the dining room by beautiful corner glazing with sliding doors it is also connect with a terrace with arcade. There is also available mirror version of this house plan.
Specifications:
- Cubature: 1120 m3 / 39547,2 ft3
- Built-up area: 139,11 m2 / 1496,82 ft2
- Total area: 375,41 m2 (with basement) / 4039,41 ft2 (with basement)
- Net area: 208,34 m2 + garage + basement + attic / 2241,74 ft2 + garage + basement + attic
- Usable area: 185,42 m2 / 1995,12 ft2
- Roof area: 242,4 m2 / 2608,22 ft2
- Roof slope: 25 degrees
- Height of the building: 9,49 m (9,94 m with foundation) / 31,13 ft (32,60 ft with foundation)
- Wide of the building: 13 m / 42,64 ft
- Length of the building: 13,13 m / 43,07 ft
- Minimum plot width: 19 m / 62,32 ft
- Minimum plot lengthi: 21,24 m / 69,67 ft
- Height of rooms: 2,74 m / 8,99 ft
Materials:
- Foundations - concrete bench and foundation walls with concrete blocks
- External walls – brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
- Ceiling - Teriva
- Roof - tile
- Elevation - thin-layer plaster on polystyrene
The costs of implementing:
| The raw state open | 74 000,00 EUR |
| The raw state closed | 99 700,00 EUR |
| The cost of finishing works | 84 400,00 EUR |
| Execution of turnkey home | 184 100,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Vega - detailed file - mirror
House plan Vega - detailed file
