Toucan house plan

Usable area: 163.71 m2   /   The cost of the realization: 146 700 EUR
House plan Toucan - front visualization
Show mirror image

Toucan house plan is a storey detached house. It is an ideal for a family of four-five people. The building is covered with a hipped roof, with an added part of the garage, and a roofed terrace on the side the garden. Toucan is a suburban villa with a traditional, elegant architecture, with a touch of modernity. Finishing details, and natural materials such as brick or wood add charm to this simple block. House is subordinated to the simplicity and functionality of the building. Clear division of rooms combine with uncomplicated design. On the ground floor is a single space of living area with living room, dining room, lobby with stately staircase, and a partially open kitchen. There is also place for an extra room - study room or a guest bedroom, and a large garage and boiler room. On the first floor are designed three spacious bedrooms with private bathrooms. Parents' bedroom is a separate suite with dressing room and private bathroom. In addition, for the utility purpose, spacious loft above the floor can be adapted. There is also available mirror version of this house plan.

  • Cubature: 920 m/ 32485,2 ft3
  • Built-up area: 150,91 m2 / 1623,79 ft2
  • Total area: 263,51 m2 / 2835,37 ft2
  • Net area: 168,09 m2 + garage / 263,51 ft2 + garage
  • Usable area: 163,71 m2 / 1761,52 ft2
  • Roof area: 246,9 m2 / 2656,64 ft2
  • Roof slope: 30 degrees
  • Height of the building: 8,87 m (9,02 m with foundation) / 29,09 ft (29,58 ft with foundation)
  • Wide of the building: 15,34 m / 50,31 ft
  • Length of the building: 12,47 m / 40,90 ft
  • Minimum plot width: 22,22 m / 72,88 ft
  • Minimum plot lengthi: 20,47 m / 67,14 ft
  • Height of rooms:  2,75 i 2,55 m / 9,02 ft and 8,36 ft
  • Foundations - concrete bench and foundation walls with concrete blocks
  • External walls –  brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
  • Ceiling -  Teriva
  • Elevation - thin-layer plaster on polystyrene
  • Roof -  tile



The costs of implementing:
The raw state open 51 800,00 EUR
The raw state closed 74 300,00 EUR
The cost of finishing works 72 400,00 EUR
Execution of turnkey home 146 700,00 EUR

Net notified costs, do not include VAT

To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.

House plan Toucan - detailed file

House plan Toucan - detailed file - mirror

Toucan house plan 3187 Krystyna
2012.10.12 0 Pozytywny komentarz Negatywny komentarz

I must admit that despite the small area the house has a lot of functions. For me, a very shapely and interesting house plan.

Toucan house plan 2586 Marlena Zawadzka
2012.03.14 0 Pozytywny komentarz Negatywny komentarz

I wonder about the purchase this project, but I want to set up solar panels, whether it is possible in this house?

MG Projekt answer
Hello. In this house you can easily install the solar system - you can buy it from us as the addition to the basic version the package of solar installation. MG
Toucan house plan 2587 Jan Tymiński
2012.03.02 0 Pozytywny komentarz Negatywny komentarz

This house is terrific. More than six months we were looking for a home that would meet while in 80% our expectations, this project turned out to be the fulfillment of our needs in 100%, we cannot believe it :)
