Flea with garage house plan

Usable area: 83.13 m² / The cost of the realization: 80 900 EUR

House plan Pchelka with garage - front visualization

Show mirror image

Price: 900 EUR

Description Plans Elevations Situations Animation Variants (0) Realizations (29) Detailed drawings List of materials Comments (3)

Flea with garage house plan is a variant version of Flea, this time with a later extension garage. House is designed for four to five people, it can be used as a family all year round or as a holiday house. The simple shape of the building covered with a gable roof has been varied by small roofs with large eaves - especially the original roof over the entrance to the house. Convenient garage was built another to one side of house and covered with a prolonged roof of the house. House is very neat, has a well-balanced proportions and scale. Due to the clear layout design house construction should be easy and inexpensive. Inside the house, on the ground floor was planned living-dining room with kitchen, utility room, bathroom and room - master bedroom. In the attic was planned two children bedrooms and a bathroom. Flea with garage is designed to be able to finish the attic in the second stage. There is also available a mirror version of this house plan.

Specifications:

Cubature: 356 m³ / 12570,36 ft³
Built-up area: 101,36 m² / 1090,63 ft²
Total area: 135,41 m² / 1457,01 ft²
Net area: 88,54 m² / 952,69 ft²
Usable area: 83,13 m² / 894,48 ft²
Roof area: 170,03 m² / 1829,52 ft²
Roof slope: 30 degrees
Height of the building: 6,30 m (6,60 m with foundation) / 20,66 ft (21,65 ft with foundation)
Wide of the building: 12,27 m / 40,25 ft
Length of the building: 9,9 m / 32,47 ft
Minimum plot width: 19,27 m / 63,21 ft
Minimum plot length: 18,88 m / 61,93 ft
Height of rooms: 2,65 m / 8,69 ft

Materials:

Foundations – poured concrete
External walls – bilayer walls - aerated concrete 24 + polystyrene 15 or mineral wool
Ceiling - reinforced concrete TERIVA
Roof - tile or meatal roofing tile
Elevation - thin-layer plaster

The costs of implementing:

The raw state open	29 800,00 EUR
The raw state closed	42 300,00 EUR
The cost of finishing works	38 600,00 EUR
Execution of turnkey home	80 900,00 EUR

Net notified costs, do not include VAT

Order

Additions to the project:

Energy-saving package free

Ventilation and fireplace package 90,00 EUR

Central vacuum package 70,00 EUR

The electronic version of the project 120,00 EUR

Solar installation package 70,00 EUR

Underfloor heating package 80,00 EUR

Heat pump package 70,00 EUR

Water jacket package 70,00 EUR

Boiler for solid fuel package 80,00 EUR

Air conditioning package 80,00 EUR

Fencing projects 140,00 EUR

Septic tanks sealed package free

Projekt domu Pchełka z garażem - zestawienie materiałowe

To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.

House plan Pchelka with garage - detailed file

House plan Pchelka with garage - detailed file - mirro
