Crumb house plan

Usable area: 66.62 m2   /   The cost of the realization: 48 700 EUR
House plan Okruszek - front visualization
Show mirror image


Crumb house plan is an extended version of Pine house plan. The building has been increased by utility room on the ground floor, porch with a visor before entering and partly covered terrace. Crumb house plan is a great option for a small family, it can serve both as a holiday house as well as year-round. The building is cheap in construction and subsequent operation. Its shape has been formed with a view to possible expansion. Partial basement can be helpful when you need to place in your home for example hydrovor. There is a large living room with fireplace on the ground floor, with access to a partially covered terrace. In the attic we designed two large bedrooms. Our studio has a mirror version of Crumb and the version without basement or with complete basement.

Specifications:
  • Cubature: 317 m3 / 11193,27 ft3
  • Built-up area: 55,88 m2 / 601,27 ft2
  • Total area: 79,74 m2 + basement / 858,00 ft2 + basement
  • Net area: 66,62 m2 + basement / 716,83 ft2 + basement
  • Usable area: 66,62 m2 / 716,83 ft2
  • Roof area: 122,5 m2 / 1318,10 ft2
  • Roof slope: 45 degrees
  • Height of the building: 6,68 m (7,00 m with foundation) / 21,91 ft (22,96 ft with foundation)
  • Wide of the building: 8,8 m / 28,86 ft
  • Length of the building: 7,55 m / 24,76 ft
  • Minimum plot width: 17,2 m / 56,42 ft
  • Minimum plot length: 15,55 m / 51,00 ft
Materials:
  • Foundations – poured concrete
  • External walls –  brick walls - aerated concrete + polystyrene or ceramic brick + polystyrene
  • Ceiling -  wood or reinforced concrete Teriva
  • Elevation - thin-layer plaster
  • Roof -  tile or meatal roofing tile






The costs of implementing:
The raw state open 13 900,00 EUR
The raw state closed 22 000,00 EUR
The cost of finishing works 26 800,00 EUR
Execution of turnkey home 48 700,00 EUR

Net notified costs, do not include VAT



To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.



House plan Okruszek - detailed file

House plan Okruszek - detailed file - mirror

Comment
Crumb house plan 2029 Tomek Fijałkowski
2012.03.17 0 Pozytywny komentarz Negatywny komentarz

This house is terrific. More than six months we were looking for a home that would meet while in 80% our expectations, this project turned out to be the fulfillment of our needs in 100%, we cannot believe it :)

Crumb house plan 566 Norbuś_54
2012.02.09 0 Pozytywny komentarz Negatywny komentarz

The project is great well planned interior (maximum functional), and this simple home architecture without complicated solutions that will reduce the costs of building, a great house at a reasonable price.

Crumb house plan 2026 Patrycja Biadoń
2012.01.30 5 Pozytywny komentarz Negatywny komentarz

I'll also build this house, in my case decided minimalism: simple and easy to build solid of curiously designed interior.
