Usable area: 149.71 m2 / The cost of the realization: 139 800 EUR
Show mirror image
Price: 1070 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Detailed drawings
List of materials
Comments (3)
Turquoise house plan is a storey building, perfect for a family of four-five-people. House is covered by a hipped roof. It has also built another garage. House was designed as an elegant, combining modernity and tradition small urban villa. Building has energy efficient compact body, fairly simple construction and is easy to build. On upper floor are bedrooms without slants. Combining classic shape with interesting details such as corner windows, arcades, bay windows, parts of walls clad by clinker, form a coherent whole. House Turquoise is at the same time unique and restrained in its expression. Turquoise interior is divided into a living area on the ground floor and bedrooms upstairs. The ground floor is a single space of the living room, dining annex, lobby and partly open kitchen. It was planned also an extra room (for example. study room) and technical background - a garage with a boiler room. On the ground floor for special attention deserve beautifully stairs to the first floor and a fireplace in the center of the living room. Upstairs are three bedrooms with bathrooms, including parents’ bedroom with its own dressing room, bathroom and a balcony overlooking the garden. Additionally, you can adapt the attic above the garage - available from the hall. There is also available mirror version of this house plan.
Specifications:
- Cubature: 798 m3 / 28177,38 ft3
- Built-up area: 150,35 m2 / 1617,77 ft2
- Total area: 249,51 m2 / 2684,73 ft2
- Net area: 157,61 m2 + garage/ 1695,88 ft2 + garage
- Usable area: 149,71 m2 / 1610,88 ft2
- Roof area: 245,02 m2 / 2636,42 ft2
- Roof slope: 30 degrees
- Height of the building: 8,96 m (9,26 m with foundation) / 29,39 ft (30,37 ft with foundation)
- Wide of the building: 14,62 m / 47,95 ft
- Length of the building: 13,87 m / 45,49 ft
- Minimum plot width: 20,62 m / 67,63 ft
- Minimum plot lengthi: 21,87 m / 71,73 ft
- Height of rooms: 2,8 m / 9,18 ft
Materials:
- Foundations - concrete bench and foundation walls with concrete blocks
- External walls – brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
- Ceiling - Teriva
- Elevation - thin-layer plaster on polystyrene
- Roof - tile
The costs of implementing:
| The raw state open | 48 400,00 EUR |
| The raw state closed | 73 900,00 EUR |
| The cost of finishing works | 66 000,00 EUR |
| Execution of turnkey home | 139 800,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Turquoise - detailed file
House plan Turquoise - detailed file - mirror
