Usable area: 189.6 m2 / The cost of the realization: 133 100 EUR
Show mirror image
Price: 1070 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Realizations (20) Detailed drawings
List of materials
Comments (3)
Acacia house plan is a comfortable, large house. The building was designed without compromise, division into small rooms or without resignation from the necessary function. Nice proportional shape of the building is topped with a pediment roof heavily accented entrance, in the form of representative arcades, supported on columns. Acacia house plan is a great example of urban style. Thanks to the simple body of the building the cost of the building is beneficial with respect to the obtained surface. Acacia house plan is also available in a mirror version.o.
Specifications:
- Cubature: 735 m3 / 25952,84 ft3
- Built-up area: 150,73 m2 / 1621,85 ft 2
- Total area: 261,92 m2 / 2818,26 ft 2
- Net area: 195,57 m2 + garage 19,24 m2 / 2104,33 ft2+ garage 201,02 ft2
-
Usable area:
- 189,60 m2 + attic by PN-70/B-02365 / 2040,10 ft2 + attic by PN-70/B-02365
- 195,57 m2 + garage by PN-ISO 9836:1997 / 2104,33 ft2 + garage by PN-ISO 9835:1997
- Roof area: 235,8 m2 / 2537,21 ft2
- Roof slope: 38,5 degreesi/ 38,5 degress
- Height of the building: 8,26 m (8,66 m with foundation) / 27,09 ft ( 28,40 ft with foundation)
- Wide of the building: 14,7 m / 48,22 ft
- Length of the building: 11,16 m / 36,60 ft
- Minimum plot width: 22,7 m / 74,46 ft
- Minimum plot length: 20,16 m / 66,13 ft
- Height of rooms: 2,75 m / 9,02 ft
Materials:
• Foundations - poured out concrete
• External walls – cellular concrete blocks + polystyrene
• Ceiling - reinforced concrete Teriva
• Elevation - thin-layer plaster
• Roof - metal roofing tile or ceramic tile
The costs of implementing:
| The raw state open | 58 500,00 EUR |
| The raw state closed | 72 100,00 EUR |
| The cost of finishing works | 61 000,00 EUR |
| Execution of turnkey home | 133 100,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Acacia - detailed file - mirror
House plan Acacia - detailed file
