Usable area: 102.8 m2 / The cost of the realization: 78 500 EUR
Show mirror image
Price: 940 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Detailed drawings
List of materials
Comments (3)
Michalina is a charming detached house - implemented as a "little brother" of the Michael house plan - both houses are similar in size and layout of the interior, varying the shape of the roof. Michalina house was designed for a family of four people- this is one floor building with the usable attic. The ground floor provides living area, with a living room, a dining room, a nice open kitchen hall and a large boiler room. On the top floor are three bedrooms and a comfortable bathroom. The traditional shape of the building, constructed on a square plan, has been covered by a gable roof.
The roof is designed so that the end walls of the house were front and garden elevation. The façade is decorated with shapely roof emphasizing entrance. From the garden side is designed balcony on columns, which is also a terrace roof. The architecture of the house is quiet, at the same time retain the correct proportions of body. Used modern materials and interesting colors give a good effect of entirety. Michalina is an excellent option for investors looking for a small, comfortable house for his family, taking into account cost savings, simplicity of construction and low cost of house maintenance. There is also mirror version of Michalina house.
Specifications:
- Cubature: 437 m3 / 15430,47 ft3
- Built-up area: 79,50 m2 / 855,42 ft2
- Total area: 139,84 m2 / 1504,68 ft2
- Net area: 109,61 m2 / 1179,40 ft2
- Usable area: 102,80 m2 / 1106,13 ft2
- Roof area: 148,13 m2 / 1593,88 ft2
- Roof slope: 42 degrees
- Height of the building: 8,23 m (8,53 m with foundation) / 26,99 ft (27,98 ft with foundation)
- Wide of the building: 9,36 m / 30,70 ft
- Length of the building: 8,86 m / 29,06 ft
- Minimum plot width: 17,23 m / 56,51 ft
- Minimum plot length: 17,36 m / 56,94 ft
- Height of rooms: 2,60 m / 8,53 ft
Materials:
- Foundations - concrete bench and foundation walls with concrete blocks
- External walls – brick walls –porotherm 25 blocks + polystyrene + thin-layer plaster
- Ceiling - Teriva
- Roof - tile
- Elevation - thin-layer plaster on polystyrene
The costs of implementing:
| The raw state open | 32 100,00 EUR |
| The raw state closed | 46 000,00 EUR |
| The cost of finishing works | 32 600,00 EUR |
| Execution of turnkey home | 78 500,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Michalina - detailed file
House plan Michalina - detailed file - mirror
Related Projects
2013.10.14 0
I must admit that despite the small area the house has a lot of functions. For me, a very shapely and interesting house plan.
2013.10.08 0
Hi all, I see that this house plan is very popular, I also chose this one and I do not regret the cottage is very cool and functional. Regards.
2012.10.02 1
I wonder about the purchase this project, but I want to set up solar panels, whether it is possible in this house?
Hello. In this house you can easily install the solar system - you can buy it from us as the addition to the basic version the package of solar installation. MG
