Usable area: 176.3 m2 / The cost of the realization: 138 800 EUR
Show mirror image
Price: 1000 EUR
Description
Plans
Elevations
Situations
Animation Variants (1)
Realizations (5) Detailed drawings
List of materials
Comments (3)
Spacious house plan is a family house for a family of four-five people, designed for plots with an unfavorable access by road. Salon has been scheduled the same side of the building at the entrance. These functions, however, are separated: in the right corner of the was designed entrance door to the house and a driveway - seen from the kitchen corner of the window. In the project of house arcade and spacious terrace, which is an extension of living room are located in the left corner. There is also available mirror version of this house plan.
Specifications:
- Cubature: 735 m3 / 25952,85 ft3
- Built-up area: 146,74 m2 / 1578,92 ft2
- Total area: 256,55 m2 / 2760,48 ft2
- Net area: 208 m2 / 2238,08 ft2
- Usable area: 176,3 m2 / 1896,99 ft2
- Roof area: 261,2 m2 / 2810,51 ft2
- Roof slope: 40 degrees
- Height of the building: 8,45 m (8,97 m with foundation) / 27,72 ft (29,42 ft with foundation)
- Wide of the building: 16,94 m / 55,56 ft
- Length of the building: 11,76 m / 38,57 ft
- Minimum plot width: 25,94 m / 85,08 ft
- Minimum plot lengthi: 18,76 m / 61,53 ft
- Height of rooms: 2,60 m / 8,52 ft
Materials:
- Foundations – poured reinforced concrete
- External walls - three-layered wall aerated concrete 24 + 12 mineral wool+ 12 aerated concrete , lub 25 porotherm + 12 mineral wool + 12 checker
- Strop - żelbetowy Teriva
- Elewacje - tynk klasyczny
- Pokrycie dachu - dachówka ceramiczna lub blachodachówka
The costs of implementing:
| The raw state open | 46 200,00 EUR |
| The raw state closed | 68 100,00 EUR |
| The cost of finishing works | 70 800,00 EUR |
| Execution of turnkey home | 138 800,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Spacious - detailed file
House plan Spacious - detailed file - mirror
