Usable area: 93.35 m2 / The cost of the realization: 83 600 EUR
Show mirror image
Price: 870 EUR
Description
Plans
Elevations
Situations
Animation Variants (0)
Detailed drawings
List of materials
Comments (3)
Pooh house plan is a a detached house with usable attic for a family of 4-5 people. House with garage extended in front by the front wall of the building fits perfectly to a narrow plot of land or plot on a busy street, where the investor wants to acoustically and visually separate themselves from the road. Pooh house plan, although it is little has on the ground floor a spacious living room with fireplace, with dining area, open to the kitchen and hall, with visible staircase. In the attic there are three bedrooms and a bathroom. The house is simple in the structure and easy in construction. Sympathetic, graceful appearance goes hand in hand with a comfortable and functional interior. There is also available mirror version of this house plan.
Specifications:
- Cubature: 463 m3 / 16348,53 ft3
- Built-up area: 92,2 m2 / 992,07 ft2
- Total area: 138,04 m2 / 1485,31 ft2
- Net area: 115,14 m2 with garage / 1238,91 ft2 with garage
- Usable area: 93,35 m2 / 1004,45 ft2
- Roof area: 179 m2 / 1926,04 ft2
- Roof slope: 42 degrees
- Height of the building: 7,40 m (7,72 m with foundation) / 24,27 ft (25,32 ft with foundation)
- Wide of the building: 7,96 m / 26,11 ft
- Length of the building: 17,2 m / 56,42 ft
- Minimum plot width: 14,96 m / 49,07 ft
- Minimum plot lengthi: 24,2 m / 79,38 ft
- Height of rooms: 2,63 m / 8,63 ft
Materials:
- Foundations - concrete bench and foundation walls with concrete blocks
- External walls - bilayer - aerated concrete + polystyrene
- Internal walls - aerated concrete
- Ceiling - Teriva
- Roof - tile
- Elevation - thin-layer plaster
The costs of implementing:
| The raw state open | 28 000,00 EUR |
| The raw state closed | 43 900,00 EUR |
| The cost of finishing works | 39 800,00 EUR |
| Execution of turnkey home | 83 600,00 EUR |
Net notified costs, do not include VAT
Additions to the project:
To see simplified technical drawings of the house plan, please click on the link below. Select the house plan version that you interest - the basic or mirror version. The pdf file with dimensional drawings: floor plans, sections and elevations will open in a separate window. You can zoom in, zoom out and move the drawings on the screen. You can also print or save the drawings.
House plan Pooh - detailed file - mirror
House plan Pooh - detailed file
